The clinical significance of elastic lamina invasion in patients with pStage II colorectal cancer: a notable prognostic indicator

Abstract

Background

Some colorectal cancers (CRCs) are clinically diagnosed as cT4a with serosal invasion (SI). However, the cT4a is most often underdiagnosed pathologically as pT3 without SI by hematoxylin–eosin (H&E) staining alone. Using Elastica van Gieson (EVG) staining, some pT3 tumors invade the elastic lamina (EL), which extends just below the serosal layer. Recently, EL invasion (ELI) has been described as a poor prognostic factor for disease-free survival (DFS) and overall survival (OS) in patients with pStage II CRC. However, its clinicopathological significance remains unclear due to the limited number of studies and poor understanding of ELI.

Objective

This study investigated the association between the ELI and patient prognosis.

Methods

After 1982, pathological diagnosis was routinely performed using H&E and EVG staining methods, and long-term follow up was performed until 2016. All clinicopathological features including ELI were prospectively registered into our computer and 569 patients with pStage II CRC were collected from the database. Based on the ELI status, pT3 was divided into three pathological categories: pT3ELI − was defined as pT3a, pT3ELI + as pT3b and unidentified EL (pT3EL −) as pT3u.

Results

Using H&E staining alone, gross cT4a was most often pathologically underdiagnosed as pT3 (93.8%) and very rarely as pT4a, resulting in a large diagnostic discrepancy. Using EVG staining, 60.7% of the cT4a tumors were diagnosed as pT3b. The 10-year DFS and OS rates were similar for pT3a and pT3u patients. However, the 10-year DFS and OS rates of pT3b patients were significantly lower than those of pT3a patients (75.6% vs. 95.6%, p < 0.0001 and 58.4% vs. 70.6%, p = 0.0024, respectively) but did not differ from those of pT4a patients (70.6%, p = 0.5799 and 52.0%, p = 0.1116, respectively). Multivariate analysis revealed that the ELI was the strongest independent risk factor for recurrence and CRC-specific death (p < 0.0001).

Conclusions

A better understanding of the ELI allows us to reconsider the diagnostic discrepancy of serosal invasion, i.e., pT3b should be considered pT4a. The ELI-based subclassification of pT3 is expected to be incorporated into the TNM staging system in the future. The ELI is a notable prognostic indicator in patients with pStage II CRC.

Introduction

Colorectal cancer (CRC) is one of the most common cancers in the world [1]. Some CRCs are diagnosed clinically as cT4a with serosal invasion (SI). With hematoxylin–eosin (H&E) staining alone, cT4a is most often underdiagnosed pathologically as pT3without SI, i.e., invasion into subserosa or non-peritonealized pericolic/perirectal tissue, and very rarely as pT4a with high risk potential for peritoneal recurrence [2,3,4,5]. There is a large discrepancy in the diagnosis of SI [6]. The distinction between pT3 and pT4a tumors continues to be a source of diagnostic confusion [7,8,9,10,11,12,13]. One of the reasons for the diagnostic difficulty appears to be the diagnosis based on H&E staining alone, as noted by Lu [14]. However, according to the results of Elastica van Gieson (EVG) staining, some pT3 tumors invade the elastic lamina (EL), which extends just below the serosal layer. Therefore, some authors have reported that pT3 disease with ELI + is considered to be occult pT4a disease [3, 8, 15]. In addition, Liang [16] proposed that pT3 with ELI + should be considered pT4a. Moreover, the ELI + has been recently described as a poor prognostic factor in patients with pStage II CRC [7, 17,18,19,20]. In lung cancer, the 7th edition of the TNM staging system [21] defines ELI as positive pleural invasion. Several studies have reported that the ELI is associated with poor prognosis in lung cancer, gastric cancer [22,23,24], and pT3N0/N ( +) CRC [7, 16,17,18,19,20, 25]. However, the TNM staging system 8th edition [26] has not yet defined the ELI in CRC. This may be because the clinicopathological significance of the ELI remains unknown. The pathological features of ELI were previously studied by the author (KS) and were briefly described in the research article published in 1984 [27]. On this occasion, the author reevaluated its clinicopathological significance and addressed issues that have long been questioned by surgeons. The present study improves the understanding of the ELI and highlights the prognostic differences in patients with ELI-based subclassification of pT3 tumors. The diagnostic discrepancy between gross and pathological SI (cT4a/pT4a) is also discussed from the perspective of the ELI.

Methods

Study design and inclusion/exclusion criteria

This was a retrospective cohort study. The data were collected from the computerized original database initiated by the author (KS) in 1982 [28,29,30,31,32]. Prospectively registered records from January 1982 to December 2013 were reviewed. A total of 3364 patients with CRC underwent surgical treatment. Of these, 569 patients with pStage II (pT3/pT4a) disease had a primary CRC and underwent curative surgery. Any cT4b/pT4b cases were not included in this study. All the tumors were located proximal to the peritoneal reflection, where the intestine is surrounded by the serosal membrane. Patients with multiple primary cancers, those who received neoadjuvant chemotherapy, and those who died in the hospital were excluded. Fourteen patients (2.5%) were lost to follow-up and were excluded from this study.

Tumor location and surgical procedures

There were 198 patients in the right colon, 295 in the left colon and 76 in the intraperitoneal rectum. In accordance with Japanese clinical practice guidelines [33], D3 lymph node (LN) en-bloc dissection [34] was performed in 476 patients, but D2/D1 LN dissection was performed in 93 patients depending on their preoperative health status. Prior to 1995, 545 patients underwent open surgery. Subsequently, 24 patients underwent laparoscopic surgery.

Processing of resected specimens

The processing of resected specimens has been previously reported [28,29,30,31,32]. Briefly, the serosal surface of fresh resected specimens was carefully observed to diagnose cT3 or cT4a tumors. The mesenteric LNs were harvested immediately after surgery. Pericolic/perirectal LNs close to the main tumor were never harvested to avoid damaging the serosal membrane and extramural adipose tissue. After formalin fixation for 1 week, the entire tumor mass, including serosa and extramural adipose tissue, was cut longitudinally along the long axis of the bowel into large step-shaped sections of 5–6 mm thickness, including the oral and anal edges of the tumor. Depending on the tumor situation, the tumor mass was cut perpendicular to the long axis of the bowel to confirm the serosal invasion. All blocks were then embedded in paraffin after alcohol dehydration. Thin 4–5 μm sections were cut from the paraffin-embedded blocks. All thin sections were routinely stained with both H&E and EVG since 1982.

Typical ELI and definition of pT3 classification

The author (KS) was responsible for the final pathological diagnosis of each patient from 1982 until 2014, when he retired. All pathological findings including the ELI were sketched in detail on an ISO B4 size paper as previously reported [32]. The elastic lamina (EL) is occasionally breached or disrupted by tumor or desmoplastic reaction, but can be traced by identifying fragments of elastic fibers. A typical ELI is shown in Fig. 1. H&E and EVG stained micrographs of the same case were shown in a vertical row. ELI − indicates that the tumor invasion does not exceed the EL, ELI + indicates that the tumor invasion exceeds the EL, and EL − indicates that the EL is unidentified. pT3 was sub-classified into three groups: pT3ELI − was defined as pT3a (Fig. 1a, EVG), pT3ELI + as pT3b (Fig. 1b, EVG), and pT3EL − as pT3u (Fig. 1c, EVG). pT4a was defined as cancer cells exposed to the serosal surface or in the peritoneal cavity (Fig. 1d, H&E and EVG), according to the TNM staging system 8th edition [26].

Fig. 1
figure 1

Typical Elastic Lamina Invasion and Definition of pT3 Classification. H&E and EVG stained micrographs of the same case were shown in a vertical row. Arrow heads: elastic lamina (EL); ELI − : negative elastic lamina invasion; ELI + : positive elastic lamina invasion; EL − : unidentified elastic lamina. a Sigmoid colon cancer; Cancer cells do not invade the EL, i.e. pT3ELI − is defined as pT3a. b Sigmoid colon cancer; Cancer cells invade beyond the EL, i.e. pT3ELI + is defined as pT3b. c Ascending colon cancer confined to the posterior wall; EL is not identified in the adipose tissue of the adventitia, i.e. pT3EL − is defined as pT3u. d Rectosigmoid colon cancer: Cancer cells are exposed to the serosal surface and peritoneal cavity, defined as pT4a

Criteria of histologic differentiation, venous invasion, lymphatic invasion, perineural invasion and tumor budding

Histologic differentiation was briefly described according to Japanese classification of colorectal carcinoma [35]. Well differentiated adenocarcinoma was characterized by distinct and large gland formation and moderately differentiated adenocarcinoma was composed of medium to small glands, which is intermediate between well and poorly differentiated adenocarcinoma. Poorly differentiated adenocarcinoma was characterized as cancers with indistinct gland formation. Mucinous adenocarcinoma was characterized by cancer cells that produce substantial amount of mucus outside the cells forming mucus nodules or lakes. The criteria of venous invasion, lymphatic invasion, perineural invasion, and budding were previously reported. Briefly, venous invasion was assessed by EVG staining and was defined as cancer cells within veins with an unequivocal elastic fiber [28]. Lymphatic invasion was defined as cancer cells floating within a lymphatic endothelial-lined lumen, distinct from those within the space due to the tissue shrinkage artifact. [29]. Perineural invasion was defined as cancer cells invading the perineural space of extramural nerve bundles or cancer cells invading Auerbach's plexus [30]. The budding was defined as isolated undifferentiated cancer cells at the tumor invasive front. The term "budding" was coined by the author K.S. in the 1980s, and reported by his colleague Morodomi in 1989 [36]. This nomenclature was introduced to the world by Western researchers in 2012 and 2016 [37, 38].

In addition, pN0 cases with tumor deposits are currently defined as pN1, i.e. pStage III. Therefore, these cases were not included in this study.

Postoperative adjuvant chemotherapy

Postoperative adjuvant chemotherapy with oral 5-Fu-based regimens was administered to 240 patients (42.2%).

Follow-up examination

The date of the outpatient visit was recorded as the date of survival confirmation. The routine program included serum tumor marker measurements, chest radiography and abdominal ultrasound every three months for the first three years, every six months for the next two years and annually thereafter. When recurrence was suspected, a definitive diagnosis was made using computed tomography and/or magnetic resonance imaging. Local recurrence was defined as tumors occurring in the peritoneal cavity or pelvis within the field of the initial surgery. Distant metastases were defined as the tumors observed in the liver, lung, or other hematogenous organs. Other recurrences included peritoneal dissemination or intra/extra-abdominal LN metastases. Follow-up began in 1983 and was performed annually [28,29,30,31,32]. The author (KS) was involved in the follow-up work until the end of September 2016.

Statistical analysis

Statistical analyses were performed using StatView software (version 5.0 J; SAS Institute, Inc. Cary NC, USA). Pearson's chi-square (χ2) test and logistic regression analyses were performed to estimate correlations and the risk of recurrence for categorical variables. Univariate and multivariate Cox regression analyses were performed to identify independent prognostic factors. The Kaplan–Meier method was used to calculate time-dependent survival probabilities. The log-rank (LR) test was performed to estimate the differences in survival. All the statistical tests were two-tailed, and p < 0.05 was considered to indicate statistical significance, with confidence intervals (CIs) of 95% for hazard ratios (HRs) and odds ratios (ORs).

Survival analyses

Disease-free survival (DFS) was defined as the time from the date of surgery to the date of the first confirmed tumor recurrence or CRC-related death. Overall survival (OS) was defined as the time from the date of surgery to the date of death from any cause. All deaths were considered events.

Results

Identification of EL and ELI

A total of 4910 block sections were obtained from the resected specimens of 569 patients (mean 8.6, standard deviation [SD] 3.2; range 4–20, median 8.0). EL was identified in 91.4% (520/569), and was unidentified in 8.6% (49/569) (Tables 1a, b). EL was well identified in sigmoid colon (S) and rectosigmoid colon (Rs) cancers. EL was not identified in 8–9% of cecum (C) and transverse colon (T) cancers, and was difficult to identify in 11–15% of ascending colon (A), descending colon (D), and intraperitoneal rectal (Ra) cancers (Table 1a). The combined categories A + D + Ra and C + T + S + Rs were significantly correlated with the frequency of EL identification (p = 0.014). In addition, EL was not identified in a significantly greater percentage (34.7%) of tumors < 3 cm in size (p < 0.0001, Table 1b). Regarding the circumferential distribution of A, D and Ra cancers, the unidentified rate was significantly higher for the posterior wall tumors (44.4%) than for other circumferential distributions (p < 0.0001, Table 1c). As shown in Table 1d, ELI + was detected in 46.7% (254/544) of the pT3 cases and in 100% (25/25) of all pT4a cases. ELI − was detected in 44.3% (241/544) of the pT3 cases. A significant correlation was found between cT and pT categories (p < 0.0001).

Table 1 Identification of Elastic Lamina (EL) and Elastic Lamina Invasion (ELI)

Gross and pathological findings of resected specimens

Fresh resected specimens are shown in Fig. 2a-c. H&E and EVG stained micrographs of the same case were shown in a vertical row. Gross findings of the serosa were unequivocal cT4a. As previously reported [13], the pathological diagnoses by H&E staining were pT3, pT3, and pT4a, respectively (Fig. 2d-f), whereas the diagnoses by EVG staining were pT3a/ELI − , pT3b/ELI + , and pT4a/ELI + , respectively (Fig. 2j-l). In the cases in Fig. 2a and b, the gross and pathological diagnoses were not concordant, but in the case of Fig. 2c, the diagnoses were compatible. This study included 356 cases with cT4a (Table 1d). Of these, 334 cases were diagnosed as pT3 (93.8%) and 22 cases (6.2%) were diagnosed as pT4a by H&E staining alone. There was a large discrepancy between the gross and pathological diagnoses of SI. Based on the ELI status, 113 cases (31.7%) were diagnosed as pT3a and 216 cases (60.7%) were diagnosed as pT3b.

Fig. 2
figure 2

Differences between Gross and Pathological Diagnoses. H&E and EVG stained micrographs of the same case were shown in a vertical row. Arrow heads: elastic lamina (EL); a) b) c) Fresh resected specimens; gross diagnosis of serosal invasion was cT4a. d) e) f) H&E staining of cT4a area at low-power view. g) h) i) H&E staining of the black circle areas at high-power view. d) e) g) h) The pathological diagnosis was pT3 by H&E staining, with a discrepancy between the gross and pathological diagnoses of serosal invasion. i) Several cancer cells in the rectangle area are exposed to the serosal surface and peritoneal cavity. The pathological diagnosis was pT4a by H&E staining alone, which was compatible with the gross diagnosis. j) k) l) EVG staining of the H&E staining areas; j) Cancer cells do not invade the EL, i.e. pT3a (ELI −), k) Fragmented ELs are seen on the left. Cancer cells invade beyond the ELs, i.e. pT3b (ELI +), l) Cancer cells invade beyond the EL and several cancer cells in the rectangle area are exposed to the serosal surface and peritoneal cavity, i.e. pT4a (ELI +)

Causes of death during long-term follow-up

The last survey for surviving patients was completed at the end of September 2016. Eligible surviving and censored patients were followed up for a mean of 127 months (range, 2–351, SD 73, median 116 months). Of these patients, 6 (2.0%) were followed up for less than 3 years, 21 (7.0%) for 3–5 years, 109 (36.1%) for 5–10 years, 135 (44.7%) for 10–20 years, and 31 (10.3%) for more than 20 years. A total of 134 patients had died of malignant disease by the end of September 2016. Of these, 72 patients (52.9%) died of primary CRC. The remaining 62 patients died mainly from second primary malignancies of the liver, stomach, or lung. Regarding non-malignant diseases, 133 patients died mainly from senility/dementia, cardiovascular, cerebrovascular or pulmonary diseases.

Postoperative recurrence

Postoperative recurrence occurred in 80 (14.1%) of the 569 patients (Table 2a). Recurrence and the pT category were significantly correlated (p < 0.0001, χ2 test). The rate of recurrence did not differ between pT3a and pT3u (4.6% vs. 6.1%, respectively) and between pT3b and pT4a (23.2% vs. 28.0%, respectively). Cumulative recurrence rates of 5- and 10-year did not differ between pT3a and pT3u and between pT3b and pT4a (p = 0.552, p = 0.580, respectively). Logistic regression analysis revealed significantly greater ORs for pT3b and pT4a than for pT3a and pT3u (p = 0.0001, OR = 6.3, 95%CI = 3.2–12.4 and p = 0.0001, OR = 8.1, 95%CI = 2.8–23.5, respectively). Among these, recurrence sites were found in 105 lesions including the liver and lung, followed by the peritoneum, local sites and others (Table 2b). To avoid statistical bias caused by the diversity of the sites, associations between the site of recurrence and the pT category were not analyzed. Distant metastasis was found at a high rate in patients in each ELI-based pT category, but the correlation was not significant (p = 0.3901; Table 2c). However, peritoneal recurrence occurred significantly more often in patients with pT3b and pT4a (26.1% and 31.8%, respectively) than in those with pT3a and pT3u (0% and 0%, respectively, p = 0.0206).

Table 2 Postoperative recurrence

Survival results

The 10-year DFS did not differ between pT3a and pT3u patients (95.6% vs. 93.8%, respectively; p = 0.5523; Fig. 3a). The 10-year OS also did not differ between the two categories (70.6% vs. 64.1%, respectively; p = 0.9429, Fig. 3b). However, as shown in Fig. 3c, patients with pT3b had a lower 10-year DFS than those with pT3a (75.6% vs. 95.6%, respectively; p < 0.0001) but were similar to those with pT4a (75.6% vs. 70.6%, respectively; p = 0.5799). They also had a lower OS than those with pT3a (58.4% vs. 70.6%, respectively; p = 0.0024, Fig. 3d), but were similar to those with pT4a (58.4% vs. 52.0%, respectively; p = 0.1116).

Fig. 3
figure 3

Cumulative survival according to the pT3 subclassification based on the ELI. DFS: disease-free survival; OS: overall survival; LR: log-rank; a) b) There were no significant differences in DFS or OS between pT3a and pT3u patients. c) d) The DFS and OS rates of patients with pT3b disease were significantly lower than those of patients with pT3a disease, but they did not differ from those of patients with pT4a disease

Univariate and multivariate analyses

Univariate analysis indicated that tumor budding, perineural invasion, and the ELI were significant risk factors for postoperative recurrence (Table 3a). After multivariate analysis, the ELI was found to be the strongest independent risk factor (p < 0.0001, HR = 4.89, 95%CI = 2.718–8.819). Similarly, these factors were found to be significant predictors of CRC-specific death (Table 3b), and on multivariate analysis, the ELI was the strongest independent predictor (p < 0.0001, HR = 6.26, 95%CI = 3.171–12.347).

Table 3 Univariate and multivariate Cox’s regression analysis for independent prognostic factors

Discussion

This retrospective cohort study clarified clinical and pathological issues, i.e., diagnostic discrepancy between cT4a and pT4a tumors, and demonstrated the close relationship between the ELI and prognosis in patients with pStage II CRC.

First of all, the serosal surface of fresh resected specimens should be carefully examined [8]. The serosal surface of cT4a often appears as whitish stripes/streaks, flattened indentation, or deep depression in fresh resected specimens [8, 15, 39] (Fig. 2a-c). Microscopically, desmoplastic reaction, isolated small glandular foci, and budding cells are usually observed on the tumor invasion front. Puppa [3] reported that when some advanced CRCs invade the serosa, the cap of fibrosis caused by a fibro-inflammatory reaction on the invasive front of the carcinoma is likely to replace areas of earlier peritoneal invasion. These serosal findings are confidently diagnosed as cT4a with SI by many surgeons at the time of surgery or on a fresh resected specimen, whereas the cT4a is most often underdiagnosed as pT3 without SI according to the TNM classification [26]. Many surgeons are surprised by this under-diagnosis. Several authors have noted the significant discrepancy between the gross and pathological diagnoses of SI [3, 6]. This diagnostic discrepancy may be due not only to diagnostic ambiguity based on H&E staining alone [13, 14, 40], but also to differences in interpretation of the clinical and pathological definitions of SI. The reported frequency of pT4a varies widely, ranging from 13.4% to 67.7% among 8 Japanese institutions [41] and the diagnostic difficulties are similar to those in other countries [9, 10]. On the other hand, when using EVG staining, some pT3 tumors invaded the EL (Fig. 2k). However there were differences in the EL identification according to tumor location and size (Tables 1a, b). Moreover, when some tumors are confined to the posterior wall, it may be difficult to identify the EL by longitudinal sectioning of the tumor in the ascending/descending colon cancer and intraperitoneal rectal cancer in which the posterior wall is not covered by serous membrane (Table 1c). In those cases, ELI can be assessed by sectioning perpendicular to the long axis to the bowel including serosa. If the tumor is sectioned in this manner, pT3u may be equivalent to pT3a. In addition, pT3u should be classified as pT3a based on the oncologic results, as described below. Several authors reported that EL was detected less frequently in right-sided tumors than in left-sided tumors [6, 42, 43], which is similar to the results found in our study. Therefore, the likelihood of EL involvement depends not only on the degree of extramural invasion, but also on the tumor location, tumor size, and circumferential distribution [44]. This problem is also more likely to occur when the number of tumor block sections is small, because the serosa may not be included. In the present study, a mean of 8.6 block sections were stained with both H&E and EVG. Lu [14] also reported that the rate of unidentified EL was 18.5%, with a mean of 3.2 sections with EVG staining. Liang [18] used only 1 EVG section per case and reported that the EL could not be identified in 58% of cases. These unidentified rates were higher than our results (8.6%, Tables 1a, b). In particular, small tumors < 3 cm should be carefully sectioned due to the high incidence of unidentified EL (34.7%, Table 1b). We believe that at least 4–5 block sections, including the serosal layer, are required to identify the EL.

Regarding the ELI, previous studies have reported that the frequency of pT3b tumors ranged from 16.7% to 52.6% [7, 17,18,19,20, 42]. Our results showed a similar frequency of 46.7% (254/544, Table 1d) as described above. In addition, as shown in Figs. 1b and 2k, the majority of cT4a cases were diagnosed as pT3b with ELI + (60.7%, Table 1d). When pT3 tumors closely infiltrate the serosal surface beyond the EL, even if a desmoplastic reaction occurs, there may be a moment when cancer cells are exfoliated into the peritoneal cavity [15]. Serosal cytologic smears demonstrated cancer cells in 19–26% of pT3 tumors [44, 45]. In other words, pT3b may be occult pT4a [3, 8, 15]. Liang [16] suggested that if ELI is present, the tumor should be considered SI positive and the stage should be pT4a. We agree with his opinion. This idea could resolve the diagnostic discrepancy between gross and pathological SI. EVG staining may be the best way to eliminate this discrepancy.

The oncological significance of the ELI has been reported to be closely associated with prognosis in lung or gastric cancer [22,23,24]. Several studies have also reported that ELI is a poor prognostic factor for pT3 CRC [7, 16,17,18,19,20, 25]. Conversely, Grin [42] reported that ELI was not a negative prognostic factor in pStage II CRC. The small number of cases may also have contributed to this difference. Liang [18] noted that some previous studies included pStage II and III disease, which did not show uniformity and introduced bias [7, 14, 16, 17, 19]. The present study specifically focused on patients with pStage II CRC to avoid any bias caused by differences in pStages [18, 42]. In addition, Japanese D3 LN en-bloc dissection [34], which is equivalent to complete mesocolic or total mesorectal excision [46, 47], appears to improve prognostic outcomes in patients with pT3a and pT3u tumors. However, patients with pT3b and pT4a had a higher risk of recurrence than those with pT3a or pT3u (p = 0.0001, OR = 6.3 and p = 0.0001, OR = 8.1, respectively; Table 2a). Cumulative recurrence rates appear to be similar between pT3a and pT3u and between pT3b and pT4a. ELI + had a strong effect on postoperative recurrence [7, 17, 18]. The top four sites of recurrence were the liver, lung, peritoneum, and local site (Table 2b), similar to the finding of other studies [7, 17, 19]. However, there are few reports on the association between distant metastasis and ELI [7, 17, 48]. Shinto [17] and Kojima [7] reported that distant metastasis occurred more frequently in the pT3b and pT4a groups than in the pT3a group. El-Aziz [48] also reported that distant metastasis rates differed significantly according to ELI status. However, in the present study, distant metastasis and the ELI-based pT category were not associated (p = 0.3901, Table 2c). On the other hand, pT4a, i.e., pathological SI, is known to be a marker for predicting peritoneal recurrence. [3,4,5]. It is easy to understand that pT4a is prone to peritoneal dissemination, because cancer cells are exposed to the serosal surface and/or exfoliated into the peritoneal cavity. To our knowledge, there are few reports on the association between the ELI and peritoneal dissemination. The present study showed that peritoneal recurrence was more strongly associated with pT3b and pT4a than with pT3a and pT3u (p = 0.0206, Table 2c), similar to the results of other studies [7, 20]. We can better understand the idea that pT3b may be occult pT4a [3, 8, 15].

In addition to the effect of D3 dissection, both pT3a and pT3u tumors appear to be low malignant, and the prognosis appears to be favorable [14, 18] (Fig. 3a, b). Conversely, the malignant potential of pT3b is considered to be much higher than that of pT3a/pT3u and very similar to that of pT4a [7, 17,18,19,20] (Fig. 3c, d). pT3b tumors appear to be a heterogeneous entity of pT3. Therefore, patients with pT3b disease should be upgraded to pT4a disease and intensive adjuvant chemotherapy is recommended. However, some authors [42, 49] have found no prognostic significance between pT3a and pT3b in terms of DFS or OS, which differed from the results of our study (Fig. 3c and d).

According to univariate and multivariate analyses, the ELI was found to have a strong effect on recurrence and CRC-specific death in patients with pT3 disease (Tables 3a, b). Other studies have shown that the ELI is an independent prognostic factor for postoperative survival [17] and is an independent risk factor for recurrence [7]. The ELI appears to be a better prognostic indicator than traditional prognostic factors such as venous [28], lymphatic [29], and perineural invasion [30]. In patients with pStage II disease, the ELI is very useful for identifying high-risk individuals, and confirming the diagnosis of SI. EVG staining is needed for identifying the ELI.

Conclusions

In conclusion, a better understanding of the ELI allows us to reconsider the diagnostic discrepancy of serosal invasion, i.e., pT3b should be considered pT4a. The ELI-based subclassification of pT3 is expected to be incorporated into the TNM staging system in the future. The ELI is a notable prognostic indicator in patients with pStage II CRC.

Data availability

No datasets were generated or analysed during the current study.

Abbreviations

CRC:

Colorectal cancer

EL:

Elastic lamina

ELI:

Elastic lamina invasion

H&E:

Hematoxylin- eosin

EVG:

Elastica van Gieson

DFS:

Disease-free survival

OS:

Overall survival

SI:

Serosal invasion

LN:

Lymph node

5-Fu:

5-Fluorouracil

LR:

Log-rank

CI:

Confidence interval

HR:

Hazard ratio

OR:

Odds ratio

SD:

Standard deviation

References

  1. Bray F, Ferlay J, Soerjomataram I, et al. Global cancer statistics 2018: GLOBOCAN Estimates of incidence and mortality worldwide for 36 cancers in 185 countries. CA Cancer J Clin. 2018;68:394–424. https://doiorg.publicaciones.saludcastillayleon.es/10.3322/caac.21492.

    Article  PubMed  Google Scholar

  2. Lennon AM, Mulcahy HE, Hyland JMP, et al. Peritoneal involvement in stage II colon cancer. Am J Clin Pathol. 2003;119:108–13. https://doiorg.publicaciones.saludcastillayleon.es/10.1309/J6BD-TWM2-M792-TN2V.

    Article  PubMed  CAS  Google Scholar

  3. Puppa G, Shepherd NA, Sheahan K, et al. Peritoneal elastic lamina invasion in colorectal cancer: the answer to a controversial area of pathology? Am J Surg Pathol. 2011;35:465–8. https://doiorg.publicaciones.saludcastillayleon.es/10.1097/PAS.0b013e31820ac84a.

    Article  PubMed  Google Scholar

  4. Shepherd NA, Baxter KJ, Love SB. The prognostic importance of peritoneal involvement in colonic cancer: a prospective evaluation. Gastroenterology. 1997;112:1096–102. https://doiorg.publicaciones.saludcastillayleon.es/10.1016/s0016-5085(97)70119-7.

    Article  PubMed  CAS  Google Scholar

  5. Kyang LS, Valle SJ, Alzahrani NA, et al. Prevention of peritoneal recurrence in high-risk colorectal cancer and evidence of T4 status as a potential risk factor. ANZ J Surg. 2018;88:975–81. https://doiorg.publicaciones.saludcastillayleon.es/10.1111/ans.14428.

    Article  PubMed  Google Scholar

  6. Compton CC. Colorectal carcinoma: diagnostic, prognostic, and molecular features. Mod Pathol. 2003;16:376–88. https://doiorg.publicaciones.saludcastillayleon.es/10.1097/01.MP.0000062859.46942.93.

    Article  PubMed  Google Scholar

  7. Kojima M, Nakajima K, Ishii G, et al. Peritoneal elastic invasion of colorectal cancer. The diagnostic utility and clinicopathological relationship. Am J Surg Pathol. 2010;34:1351–60. https://doiorg.publicaciones.saludcastillayleon.es/10.1097/PAS.0b013e3181ecfe98.

    Article  PubMed  Google Scholar

  8. Maguire A, Sheahan K. Controversies in the pathological assessment of colorectal cancer. World J Gastroenterl. 2014;20:9850–61. https://doiorg.publicaciones.saludcastillayleon.es/10.3748/wjg.v20.i29.9850.

    Article  Google Scholar

  9. Klaver CEL, Bulkmans N, Drillenburg P, et al. Interobserver, intraobserver, and interlaboratory variability in reporting pT4a colon cancer. Virchows Arch. 2020;476:219–30. https://doiorg.publicaciones.saludcastillayleon.es/10.1007/s00428-019-02663-0.

    Article  PubMed  CAS  Google Scholar

  10. Naso JR, Yang HM, Scheffer DF. Variability in synoptic reporting of colorectal cancer pT4a category and lymphovascular invasion. Arch Pathol Lab Med. 2021;145:343–51. https://doiorg.publicaciones.saludcastillayleon.es/10.5858/arpa.2020-0124-OA.

    Article  PubMed  Google Scholar

  11. Karamchandani DM, Chetty R, King TS, et al. Challenges with colorectal cancer staging: results of an international study. Mod Pathol. 2020;33:153–63. https://doiorg.publicaciones.saludcastillayleon.es/10.1038/s41379-019-0344-3.

    Article  PubMed  Google Scholar

  12. Vasques RP, Arslan ME, Lee H, et al. T3 versus T4a staging challenges in deeply invasive colonic adenocarcinomas and correlation with clinical outcomes. Mod Pathol. 2021;34:131–40. https://doiorg.publicaciones.saludcastillayleon.es/10.1038/s41379-020-0622-0.

    Article  CAS  Google Scholar

  13. Panarelli NC, Hammer STG, Lin J, et al. Reproducibility of AJCC criteria for classifying deeply invasive colon cancers is suboptimal for consistent cancer staging. Am J Surg Pathol. 2020;44:1381–8. https://doiorg.publicaciones.saludcastillayleon.es/10.1097/PAS.0000000000001510.

    Article  PubMed  Google Scholar

  14. Lu J, Hu X, Meng Y, et al. The prognosis significance and application value of peritoneal elastic lamina invasion in colon cancer. PloSONE. 2018;13(4):e0194804. https://doiorg.publicaciones.saludcastillayleon.es/10.1371/journal.pone.0194804.

    Article  CAS  Google Scholar

  15. Ludeman L, Shepherd HA. Serosal involvement in gastrointestinal cancer: its assessment and significance. Histopathology. 2005;47:123–31. https://doiorg.publicaciones.saludcastillayleon.es/10.1111/j.1365-2559.2005.02189.x.

    Article  PubMed  CAS  Google Scholar

  16. Liang WY, Wang YC, Hsu CY, et al. Staging of colorectal cancers based on elastic lamina invasion. Human Pathol. 2019;85:44–9. https://doiorg.publicaciones.saludcastillayleon.es/10.1016/j.humpath.2018.10.019.

    Article  Google Scholar

  17. Shinto E, Ueno H, Hashiguchi Y, et al. The subserosal elastic lamina: an anatomic landmark for stratifying pT3 colorectal cancer. Dis Colon Rectum. 2004;47:467–73. https://doiorg.publicaciones.saludcastillayleon.es/10.1007/s10350-003-0083-9.

    Article  PubMed  Google Scholar

  18. Liang WY, Chan WC, Hsu CY, et al. Retrospective evaluation of elastic stain in the assessment of serosal invasion of pT3N0 colorectal cancers. Am J Surg Pathol. 2013;37:1565–70. https://doiorg.publicaciones.saludcastillayleon.es/10.1097/PAS.0b013e31828ea2de.

    Article  PubMed  Google Scholar

  19. Yokota M, Kojima M, Noumra S, et al. Clinical impact of elastic laminal invasion in colon cancer: Laminal invasion-positive stage II colon cancer is a high-risk equivalent to stage III. Dis Colon Rectum. 2014;57:830–8. https://doiorg.publicaciones.saludcastillayleon.es/10.1097/DCR.0000000000000124.

    Article  PubMed  Google Scholar

  20. Nakanishi Y, LeVea C, Dibaj S, et al. Reappraisal of serosal invasion in patients with T3 colorectal cancer by elastic stain. Arch Patho Lab Med. 2016;140:81–5. https://doiorg.publicaciones.saludcastillayleon.es/10.5858/arpa.2014-0647-OA.

    Article  Google Scholar

  21. Sobin LH, Gospodarowicz MK, Wittekind C. TNM Classification of Malignant Tumours. 7th ed. Wiley-Blackwell: New York; 2009.

    Google Scholar

  22. Tian D, Pei Y, Zheng Q, Zhan J, Li S, Wang X, et al. Effect of visceral pleural invasion on the prognosis of patients with lymph node negative non-small cell lung cancer. Thoracic Cancer. 2017;8:97–105. https://doiorg.publicaciones.saludcastillayleon.es/10.1111/1759-7714.12412.

    Article  PubMed  PubMed Central  CAS  Google Scholar

  23. Yang H, Mei T. Prognostic significance of visceral pleural invasion in patients with surgically resected small-cell lung cancer: a population-based study. Jpn J Clin Oncol. 2022;52:1045–55. https://doiorg.publicaciones.saludcastillayleon.es/10.1093/jjco/hyac062.

    Article  PubMed  Google Scholar

  24. Lei G, Yang H, Hong T, et al. Elastic staining – a rejuvenated method to reassess prognosis and serosal invasion in patients with pT3N0M0 gastric cancer. Hum Pathol. 2017;65:79–84. https://doiorg.publicaciones.saludcastillayleon.es/10.1016/j.humpath.2017.04.023.

    Article  PubMed  CAS  Google Scholar

  25. Bi F, Li X, Zhang Y, et al. Prognostic value of elastic lamina staining in patients with stage III colon cancer. World J Surg Oncol. 2022;20:391–401. https://doiorg.publicaciones.saludcastillayleon.es/10.1186/s12957-022-02865-y.

    Article  PubMed  PubMed Central  Google Scholar

  26. Jessup JM, Goldberg RM, Asare EA, et al. Colon and rectum. In: Amin M, editor., et al., AJCC Cancer Staging Manual. 8th ed. Chicag: Springer Nature; 2017. p. 251–74.

    Google Scholar

  27. Shirouzu K. Clinicopathological studies on extramural local invasion and metastasis of advanced colorectal carcinomas. J Kurume Med Assoc. 1984;47:622–646. https://mol-medicalonline-jp.ejku.idm.oclc.org/library/journal/download?GoodsID=dm4kurum/1984/004706/002&name=0622-0646j&UserID=54.79.77.42&base=jamas_pdf ( In Japanese, Abstract in English).

  28. Shirouzu K, Isomoto H, Kakegawa T, et al. A prospective clinicopathologic study of venous invasion in colorectal cancer. Am J Surg. 1991;162:216–22. https://doiorg.publicaciones.saludcastillayleon.es/10.1016/0002-9610(91)90073-m.

    Article  PubMed  CAS  Google Scholar

  29. Shirouzu K, Isomoto H, Morodomi T, et al. Carcinomatous lymphatic permeation. Prognostic significance in patients with rectal carcinoma-a long term prospective study.Cancer.1995;75:4–10. https://doiorg.publicaciones.saludcastillayleon.es/10.1002/1097-0142(19950101)75:1<4::aid-cncr2820750103>3.0.co;2-q.

  30. Shirouzu K, Isomoto H, Kakegawa T. Prognostic evaluation of perineural invasion in rectal cancer. Am J Surg. 1993;165:233–7. https://doiorg.publicaciones.saludcastillayleon.es/10.1016/s0002-9610(05)80517-3.

    Article  PubMed  CAS  Google Scholar

  31. Shirouzu K, Murakami H, Ogou S, et al. High-quality follow-up system for colorectal cancer - A computer registration and administration system - J Jpn Soc Coloproctol. 2006;59:869–873 (In Japanese, Abstract in English). https://www.jstage.jst.go.jp/article/jcoloproctology1967/59/10/59_10_869/_article/-char/ja/.

  32. Shirouzu K, Ogata Y. Histopathologic tumor spread in very low rectal cancer treated with abdominoperineal resection. Dis Colon Rectum. 2009;52:1887–94. https://doiorg.publicaciones.saludcastillayleon.es/10.1007/DCR.0b013e3181b1585a.

    Article  PubMed  Google Scholar

  33. Japanese Classification of Colorectal, Appendiceal, and Anal Carcinoma: the 3d English Edition [Secondary Publication], Japanese Society for Cancer of the Colon and Rectum. J Anus Rectum Colon. 2019;3:175–195. https://doiorg.publicaciones.saludcastillayleon.es/10.23922/jarc.2019-018.

  34. Kotake K, Mizuguchi T, Moritani K, et al. Impact of D3 lymph node dissection on survival for patients with T3 and T4 colon cancer. Int J Colorectal Dis. 2014;29:847–52. https://doiorg.publicaciones.saludcastillayleon.es/10.1007/s00384-014-1885-z.

    Article  PubMed  Google Scholar

  35. Japanese Society for Cancer of the Colon and Rectum. Japanese classification of colorectal carcinoma. 1st English ed. Kanehira: Tokyo, Japan, 1997. http://www.jsccr.jp/kiyaku/index_kako_en.html.

  36. Morodomi T, Isomoto H, Shirouzu K, et al. An index for estimating the probability of lymph node metastasis in rectal cancers. Lymph node metastasis and the histopathology of actively invasive regions of cancer. Cancer;1989;63(3):539–543. https://doiorg.publicaciones.saludcastillayleon.es/10.1002/1097-0142(19890201)63:3<539::aid-cncr2820630323>3.0.co;2-s.

  37. Mitrovic B, Schaeffer DF, Riddell RH, et al. Tumor budding in colorectal carcinoma: time to take notice. Mod Pathol. 2012;25:1315–25. https://doiorg.publicaciones.saludcastillayleon.es/10.1038/modpathol.2012.94.

    Article  PubMed  CAS  Google Scholar

  38. Grigore AD, Jolly MK, Jia D, et al. Tumor budding: The name is EMT. Partial EMT J Clin Med. 2016;5(5):51. https://doiorg.publicaciones.saludcastillayleon.es/10.3390/jcm5050051.

    Article  PubMed  CAS  Google Scholar

  39. Stewart CJR, Hillery S, Platell C, et al. Assessment of serosal invasion and criteria for the classification of pathological (p) T4 staging in colorectal carcinoma: confusions, controversies and criticisms. Cancers. 2011;3:164–81. https://doiorg.publicaciones.saludcastillayleon.es/10.3390/cancers3010164.

    Article  PubMed  PubMed Central  Google Scholar

  40. Zwanenburg ES, Wisselink DD, Klaver CEL, et al. The measured distance between tumor cells and the peritoneal surface predicts the risk of peritoneal metastases and offers an objective means to differentiate between pT3 and pT4a colon cancer. Mod Pathol. 2022;35:1991–2001. https://doiorg.publicaciones.saludcastillayleon.es/10.1038/s41379-022-01154-z.

    Article  PubMed  CAS  Google Scholar

  41. Kojima M, Shimazaki H, Iwaya K, et al. Practical utility and objectivity: Does evaluation of peritoneal elastic invasion in colorectal cancer overcome these contrary problems? Letters to the editor. Am J Sug Pathol. 2014;38:145. https://doiorg.publicaciones.saludcastillayleon.es/10.1097/PAS.0000000000000121.

    Article  Google Scholar

  42. Grin A, Messenger DE, Cook M, et al. Peritoneal elastic lamina invasion: limitations in its use as a prognostic marker in stage II colorectal cancer. Human Pathol. 2013;44:2696–705. https://doiorg.publicaciones.saludcastillayleon.es/10.1016/j.humpath.2013.07.013.

    Article  CAS  Google Scholar

  43. Frankel W, Jin M. Serosal surfaces, mucin pools, and deposits, Oh my: challenges in staging colorectal carcinoma. Mod Pathol. 2015;28:S95–108. https://doiorg.publicaciones.saludcastillayleon.es/10.1038/modpathol.2014.128.

    Article  PubMed  Google Scholar

  44. Panarelli NC, Schreiner AM, Brandt SM, et al. Histologic features and cytologic techniques that aid pathologic stage assessment of colonic adenocarcinoma. Am J Surg Pathol. 2013;37:1252–8. https://doiorg.publicaciones.saludcastillayleon.es/10.1097/PAS.0b013e3182960e7c.

    Article  PubMed  Google Scholar

  45. Zeng Z, Cohen AM, Hajdu S, et al. Serosal cytologic study to determine free mesothelial penetration of intraperitoneal colon cancer. Cancer. 1992;70:737–40. https://doiorg.publicaciones.saludcastillayleon.es/10.1002/1097-0142(19920815)70:4%3c737::aid-cncr2820700404%3e3.0.co;2-s.

    Article  PubMed  CAS  Google Scholar

  46. Hohenberger W, Weber K, Matzel K, et al. Standardized surgery for colonic cancer: complete mesocolic excision and central ligation–technical notes and outcome. Colorectal Dis. 2009;11:354–64. https://doiorg.publicaciones.saludcastillayleon.es/10.1111/j.1463-1318.2008.01735.x.

    Article  PubMed  CAS  Google Scholar

  47. Heald RJ, Moran BJ. Embryology and anatomy of the rectum. Semin Surg Oncol. 1998;15:66–71. https://doiorg.publicaciones.saludcastillayleon.es/10.1002/(SICI)1098-2388(199809)15:2<66::AID-SSU2>3.0.CO;2-3.

  48. El-Aziz AMA, Ali HHM, Tabak SAEL-H, et al. Peritoneal elastic lamina changes and D2–40 expression in colorectal carcinoma: a histopathological and immunochemical study. J Clin Diagn Res. 2019;13: EC01-EC05. https://doiorg.publicaciones.saludcastillayleon.es/10.7860/JCDR/2019/42185.13113.

  49. Macchi L, Bao QR, Albertoni L, et al. Prognostic significance of additional histologic features for subclassification of pathological T3 colon cancer. Int J Clin Oncol. 2022;27:1428–38. https://doiorg.publicaciones.saludcastillayleon.es/10.1007/s10147-022-02192-y.

    Article  PubMed  PubMed Central  CAS  Google Scholar

Download references

Acknowledgements

The present study was supported by colorectal surgeons. They were involved in the surgery, long-term follow-up, and processing of resected specimens.

Funding

The authors have not received any external funding.
